Thin Film Deposition

Testing Capabilities

X-POWER offers deposition of thin films on wafers up to 100 mm or smaller sample pieces. Both sputtering (DC and RF) and e-beam deposition techniques are available in a cluster system with a load-lock and a robot for transfer of samples between units under vacuum.

The system is part of the prototyping capabilities in X-POWER where contacts from chips to external connections are investigated.

Potential to Research and Industry Service

  • Support research on development of prototypes of new components
  • Support research on contacts in power electronics
  • Support research on development of packaging solutions
Thin Film Deposition

Key Figures of Thin Film Deposition System

  • System base pressure: 10-9mbar
  • Sample temperature: Room temperature to 1000 oC
  • Sample size: From 1x1 cm2 to 100-mm wafer
  • E-beam deposition: 8x12 cc pockets
  • Sputtering: 3 Magnetrons, DC, RF, Bipolar
Photo of Si₃N₄ film on a Si wafer.
