Currently, the lab houses a total of 8 benches. The following equipment are available in the Lab:

• Grid Connected Converter Setups with Danfoss FC302 DC-AC inverter connected to the grid through an LCL filter and a 50Hz transformer
• The dSPACE DS1103 PPC is a mixed RISC/DSP digital controller providing a powerful processor for floating point calculations as well as comprehensive I/O capabilities.
• Control of converter or grid side current using PWM
• Constant power electronic loads
• Multiterminal medium voltage connection
• Danfoss Drive System for induction machine and PM synchronous motor
•  Different DC and AC Electrical machines
• TORQUE TRANSDUCER With a USB cable to PC, for a convenient measurement of the steady state and dynamic torque. Sampling frequency at 2 KHz for dynamic torque measurement.
• Software integrated with the torque transducer for on-line torque, speed, power, and torque ripple measurements.

Various professional, high-end equipment are available for the Electrical and Power Electronic Lab.

TORQUE TRANSDUCER

• With a USB cable to PC, for a convenient measurement of the steady state and dynamic torque. Sampling frequency at 2 KHz for dynamic torque measurement.
• Software integrated with the torque transducer for on-line torque, speed, power, and torque ripple measurements.
• Range from 5 Nm to 1000 Nm.
• Data catalog.

HIGH PRECISION, MULTI-CHANNEL DATA ACQUISITION SYSTEM FROM MICROSTAR LABORATORIES

• has an onboard 400 MHz AMD K6-III processor.
• provides 14-bit A/D converter resolution.
• samples analog inputs at up to 800k samples per second.
• further information from Microstar Laboratories

CHROMA PROGRAMMABLE AC/DC POWER SUPPLIER

• capable of generating ac, dc and ac dc voltages.
• available at various power range.
• More information on programmable AC/DC power supplier.

ARBITRARY FUNCTION GENERATOR (AFG-3000)

• Wide frequency range from 1μHz ~ 80/50MHz.
  16-bit, 200MSa/s, 1M-point deep arbitrary waveform.
• Arbitrary Waveform Editing PC Software.
• More information on arbitrary function generator

VARIOUS OSCILLOSCOPES AND VOLTAGE, CURRENT PROBES FROM TEKTRONIX INCLUDING THE HIGH-END DPO-4000 SERIES

• DPO2014
• DPO4054B
• TCP0030
• TCP0150
• P5100A
• P5205A

WIDEBAND POWER ANALYZER (NORMA) FOR HIGH PRECISION MEASUREMENT

GENERAL-PURPOSE LABVIEW MEASUREMENT CARDS FOR DATA ACQUISITION
